Lime flour separator

The powder Classifier is operated under negative pressure. The material for grinding is fed from the inlet of the powder separator. The vortex flow entering the primary air outlet is separated by the scattering disc......
Scope of application:

Share With:
Product Description
The powder Classifier is operated under negative pressure. The material for grinding is fed from the inlet of the powder separator. The vortex flow entering the primary air outlet is separated by the scattering disc and dispersed by the suspension and dispersion mechanism. After that, a coarse subdivision level is realized in the horizontal vortex field formed by the airflow entering through the secondary tuyere in the classification zone, and the fine powder enters the cage and is drawn from the fine powder outlet by the negative pressure air into the subsequent cyclone collector, and is collected by the collector. Finished product, the coarse powder falls into the cone and is discharged through the coarse powder outlet and returned to the mill for grinding again.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.
Feature
●     1. Easy operation and adjustable fitness;
●     2. Convenient wear parts replacement and maintenance, long service life;
●     3. Energy saving, high efficiency and large capacity;
●     4. Low investment, environmental protection and convenient installation.
Table Parameters
Model Fineness (%)  Wind Capacity (m3/h)  Rotate speed (rpm)  Power (kw)  Max capacity (t/h) Capacity (t/h)
 TS-I   0-3  16000  250-500  15  50  10-18
 TS-II   0-3  22000  220-450  18.5  90  15-28
 TS-III   0-3  30000  180-400  22  120  20-40
 TS-IV   0-3  45000  160-340  30  150  30-50
 TS-V   0-3  60000  130-300  30  210  40-70
 TS-VI   0-3  75000  130-260  37  260  50-85
 TS-VII   0-3  95000  120-240  45  330  75-110
 TS-VIII   0-3  120000  110-200  55  400  95-130
 TS-IX   0-3  150000  110-180  75  500  110-160
 TS-X   0-3  180000  110-160  110  600  130-190

Service Support




- 48-hour idling test machine before leaving the factory.

- You can take the materials to the factory test machine.

- We will customize the solution according to your needs.
