Ceramic Rotary Kiln

In the ceramic industry, rotary kilns are primarily used for the firing or sintering of ceramic products, such as pottery, tiles, refractories, and advanced ceramics. The kiln provides controlled and uniform heating to the ceramic materials, enabling them

Scope of application:
Ceramic production, cement industry, cement industry, chemical industry, waste treatment and incineration, environmental applications, etc.

Chat Now leave a message

Get A Quotation Download PDF

Share With:

Product Description

Feature Table Parameters Service Support

Product Description

As a new type of environmentally friendly materials, ceramic is widely used in petroleum, construction, chemicals, sewage treatment and other industries. Rotary kiln is the key equipment of ceramic calcining system. Its performance will directly affect the quality and cost. For the different characteristics and requirements of the traditional calcining ceramic materials, we developed the new series rotary kiln. It has the characteristics of even calcining, large capacity, high operation, energy saving, easy operation and maintenance as well as long machine life, and can reduce the equipment operating costs significantly.

Applied material: Clay, Shale, Fly Ash, Sludge

Feature

1. Ceramic rotary kilns are often insulated to minimize heat loss and improve thermal efficiency.
2. Ceramic rotary kilns include sophisticated temperature control systems.
3. Advanced ceramic rotary kilns incorporate control and monitoring systems to ensure safe and optimal operation.
4. It is micro-negative pressure operation in the cylinder with low dust pollution.

Table Parameters

Product Specification（m）	Diameter （m）	Length （m）	Capacity （t/d）	Rotation speed （r/min）	Motor power （kw）	Total weight （t）
Φ2.0×40	2	40	160	0.23-2.26	37	119
Φ2.2×45	2.2	45	180	0.21-2.44	45	128
Φ2.5×40	2.5	40	200	0.44-2.44	55	149.61
Φ2.5×50	2.5	50	250	0.62-1.86	55	187.37
Φ2.5×54	2.5	54	300	0.48-1.45	55	196.29
Φ2.7×42	2.7	42	350	0.10-1.52	55	198.5
Φ2.8×44	2.8	44	450	0.437-2.18	55	201.58
Φ3.0×45	3	45	500	0.5-2.47	75	210.94
Φ3.0×48	3	48	700	0.6-3.48	100	237
Φ3.0×60	3	60	800	0.3-2	100	310
Φ3.2×50	3.5	50	1000	0.6-3	125	278
Φ3.3×52	3.3	52	1300	0.266-2.66	125	283
Φ3.5×54	3.5	54	1500	0.55-3.4	220	363
Φ3.6×70	3.6	70	1800	0.25-1.25	125	419
Φ4.0×56	4	56	2300	0.41-4.07	315	456
Φ4.0×60	4	60	2500	0.396-3.96	315	510
Φ4.2×60	4.2	60	2750	0.41-4.07	375	633
Φ4.3×60	4.3	60	3200	0.396-3.96	375	583
Φ4.5×66	4.5	66	4000	0.41-4.1	560	710.4
Φ4.7×74	4.7	74	4500	0.35-4	630	849
Φ4.8×74	4.8	74	5000	0.396-3.96	630	899
Φ5.0×74	5	74	6000	0.35-4	710	944
Φ5.6×87	5.6	87	8000	Max4.23	800	1265
Φ6.0×95	6	95	10000	Max5	950×2	1659
