Vibrating Feeder

Hongji grizzly feeders are vibrating feeders suitable to feed any primary crusher. They are a perfect match with the primary crushers, jaw crushers, impact crushers and cone crusher so on.
Scope of application:

river pebbles, limestone, dolomite, granite, coal, diabase, basalt, construction waste, etc.

Share With:
Product Details
technical parameter
Product Description:

Hongji grizzly feeders are vibrating feeders suitable to feed any primary crusher. They are a perfect match with the primary crushers, jaw crushers, impact crushers and cone crusher so on. They have been designed for heavy duty operation and are also suitable for mining applications.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.



Features:

    1. Steady vibration, continuous and even feeding;
●     2. Pre-screening fine materials when feeding, so as to increase crushing efficiency;
●     3. Low noise and power consumption;
●     4. High working efficiency, large feeding capacity.
yuanli
Service support:



- 48-hour idling test machine before leaving the factory.

- You can take the materials to the factory test machine.

- We will customize the solution according to your needs.
yuanli
Table parameters :
Model Max. Feeding Size (mm) Processing Capacity (t/h) Motor Power (kw) Dimensions (L×W×H)(mm)
GZD-650×2300 300 80-100 1.2×2 2300×1360×780
GZD-750×2500 350 100-130 1.5×2 2500×1460×780
GZD-850×3000 400 120-150 3×2 3110×1800×1600
GZD-1000×3600 500 150-200 3.7×2 3850×1950×1630
GZD-1100×3600 580 240-300 3.7×2 3600×2050×1660
GZD-1300×3600 650 450-600 7.5×2 3900×2350×1750
GZD-1500×3600 1050 450-1000 7.5×2 3900×2000×1750
GZD-2000×3600 1200 550-1000 10×2 3600×2000×1750
GZD-2500×5000 1500 650-1500 18×2 5000×2500×1800
ZSW-380×95 500 100-180 11 3920×1640×1320
ZSW-490×110 630 150-400 15 4980×1830×1320
ZSW-490×130 750 400-700 22 4980×2580×2083
ZSW-600×130 750 400-700 22 6082×2580×2083
ZSW-600×150 800 500-900 30 6086×2662×1912
ZSW-600×180 900 700-1300 45 6310×3262×2230
ZSW-600×200 1200 800-1500 55 6310×3462×2230
