Wet magnetic separator

Magnetic separator is one of the most commonly used in the industry, and it is suitable for separating materials which have magnetism differences.
Scope of application:
Magnetic separator is used for particle size below 3mm magnetite, pyrrhotite, roasted ore, ilmenite and other materials wet magnetic separator, and also for coal, non-metallic minerals, building materials and other materials iron remover.
Share With:
Product Details
technical parameter
Product Description:

Magnetic separator is one of the most commonly used in the industry, and it is suitable for separating materials which have magnetism differences. Magnetic separator can be widely used in mining machinery, timber, ceramics, chemistry and food, etc. industries.

Applied material : Rock, gravel, different kinds of ore, fireclay, slag and other hard materials.



Features:

    1. Long life from liners of special alloy manganese steel.
●     2. The interior of the crusher is protected from dust by a self-lubricating seal ring.
●     3. Quiet operation and long life thanks to bevel gears with hardened, spiral-cut teeth.
●     4. Product curve and capacity can be optimized by adjusting the eccentric bushing supplied
with the crusher.
●     5. High reduction ratio in the secondary crushing stage.
●     6. Final grain with high cubic grain proportion.
yuanli
Service support:



- 48-hour idling test machine before leaving the factory.

- You can take the materials to the factory test machine.

- We will customize the solution according to your needs.
yuanli
Table parameters :
Model Shell diameter(mm) Shell lenght (mm) Feeding size(mm) Processing capacoty(t/h) Power(kw)
CTB6012 600 1200 2-0 10-20 1.5
CTB6018 600 1800 2-0 15-30 2.2
CTB7518 750 1800 2-0 20-45 2.2
CTB9018 900 1800 3-0 40-60 3
CTB9021 900 2100 3-0 45-60 3
CTB9024 900 2400 3-0 45-70 4
CTB1018 1050 1800 3-0 50-75 5.5
CTB1021 1050 2100 3-0 50-100 5.5
CTB1024 1050 2400 3-0 60-120 5.5
CTB1218 1200 1800 3-0 80-140 5.5
CTB1224 1200 2400 3-0 85-180 7.5
CTB1230 1200 3000 3-0 100-180 7.5
CTB1530 1500 3000 3-0 170-280 11
