Vibrating Screen

HJ series vibrating screen is a new type of circular vibrating screen product which is improved on the basis of YA and YK series, comprehensive customer site use and maintenance experience......


Share With:
Product Details
technical parameter
Product Description:
HJ series vibrating screen is a new type of circular vibrating screen product which is improved on the basis of YA and YK series, comprehensive customer site use and maintenance experience, and upgraded for heavy duty conditions.

HJ series vibrating screen can process more than 200 kinds of materials, such as quartz stone, river pebbles, calcite, dolomite, granite, basalt, iron ore, limestone, diabase, etc.
features:
Unique Jaw head structure
Unique Jaw head structure
Sealed guarantee
Extend bearing lift
DEEP Cavity brokedn
High Crushing Ratio
Even output granularity
High strength
The crusher has large capacity and high strength
High bearing capacity
The bearing pedestal adopts unitary cast steel
structure
Easy operation on outlet
More advanced movable jaw assembly
Makes it more durable
UNIQUE FLYWHEEL DESIGN
Effectively reducing vibration, the machine runs more smoothly
Table parameters :
Model Motor Power(kw) Vibrating Frequency(r/min) Max.Feeding Size (mm) Production(t/h) Dimensions(mm)(L×W×H)(mm)
2HX1545 15 780-900 200 60-500 5380×2295×1410
3HX1545 15 780-900 200 65-500 5575×2295×1990
4HX1545 18.5 780-900 200 65-500 5765×2295×1990
2HX1855 18.5 780-900 200 75-600 5680×2565×1450
3HX1855 22 780-900 200 75-600 5900×2565×2110
4HX1855 22 780-900 200 75-600 6030×2565×2500
2HX2165 30 780-900 200 85-700 7160×2990×1690
3HX2165 30 780-900 200 85-700 7380×2990×2365
4HX2165 37 780-900 200 85-700 7430×2990×2550
2HX2465 37 780-900 200 100-800 7160×3290×1690
3HX2465 37 780-900 200 100-800 7380×3290×2365
4HX2465 37 780-900 200 100-800 7430×3290×2500
2HX2765 37 780-900 200 120-900 7180×3570×1805
3HX2765 45 780-900 200 120-900 7390×3570×2445
4HX2765 45 780-900 200 120-900 7480×3570×2715
2HX3065 37 780-900 200 200-1200 7180×3870×1805
3HX3065 45 780-900 200 200-1200 7390×3870×2445
4HX3065 45 780-900 200 200-1200 7480×3870×2715
2HX3075 22×2 780-900 400 200-1300 8700×4055×1980
3HX3075 37×2 780-900 400 200-1300 8940×4120×2720
